JNDWATER Plastic Cup Automatic Cup Filling and Sealing Machine

JNDWATER Plastic Cup Automatic Cup Filling and Sealing Machine

MOQ
1 PC
Payment
T/T,L/C,Western Union,Money Gram,Cash.
Place of Origin
China,Guang Dong
Brand
JND WATER
Service
OEM, ODM, Customized
Certification
CE TUV SGS FCC
Delivery Time
Shipped within 35 days
Terms of trade
EXW,FCA,FAS,FOB,CFR,CIF,CPT,CIP,DAF,DES,DEQ,DDU
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:


JD WATER-Cup Filling And Sealing Machine | Automatic Cup Sealing Machine
JD WATER-Cup Filling And Sealing Machine | Automatic Cup Sealing Machine-1


◇◆ Application


  •

    JNDWATER cup filling machine is suitable for the filling and sealing containers such as plastic cups and bowls with liquid ,cream , jelly,milk ice-cream,fruit jam,etc.

  •

    Productive ability:1500Cups/H-16000Cups/H

  •

    Cup material:Plastic

  •

    Production Capacity :1000 Can/h -20000 Can/h

  •

    The machine functions for cup feeding,film feeding,printing,filling ,sealing and cutting are all fully automatic being controlled by a range if sensors. These ensure accurate location of the cups for filling the product and sealing and cutting of the printed top material.

  •

    There are a range of machines in the series all with the capability of filling different types and sizes of containers.

  •

    All machines are manufactured by food grade stainless steel and utilize the lastest technology.

  •

    Shenzhen J&D Drinking Water Equipment Co.,Ltd. can also manufacture machines to individual customer’s specifications.

  •

    Cup rinsing is optional.



◇◆ Product  Details
JD WATER-Cup Filling And Sealing Machine | Automatic Cup Sealing Machine-2
JD WATER-Cup Filling And Sealing Machine | Automatic Cup Sealing Machine-3
JD WATER-Cup Filling And Sealing Machine | Automatic Cup Sealing Machine-4


◇◆ Technical Parameters

Technical Parameters of the Plastic Cup Filling Machine

Specification


Model

JND-2C

JND-4C

JND-6C

JND-8C

JND-10C

JND-16C

Power supply

3380V/50Hz

3380V/50Hz

3380V/50Hz

3380V/50Hz

3380V/50Hz

3380V/50Hz

Power (KW/H)

2

3.2

5

6.5

8.2

12

Productive ability (Cups/H)

1500- 2100

3000- 4100

4500- 6000

6500- 7500

7000- 10000

14000- 16000

Air pressure (Mpa)

00.65-0.85

00.65-0.85

00.65-0.85

00.65-0.85

00.65-0.85

00.65-0.85

Air consumption (M3/Min)

0.6

0.7

0.8

0.8

0.9

1.0

Total weight (Kg)

700

800

900

1000

1100

1400

Dimension (L*W*H)(mm)

3000 *600 *1500

3200 *780 *1500

3200 *950 *1500

3500 *780 *1500

3500 *950 *1500

4200 *1200 *1500



◇◆ Product advantages


Electronic Component come from famous manufacturers all over the world ,such as Omron,Siemens and so on.

Product by CE standard.

All the part which touch liquid use food grade stainless steel 304.

JD WATER-Cup Filling And Sealing Machine | Automatic Cup Sealing Machine-5

◇◆ Product  certificate


All the machines are produced by CE standard and we also have CE certificate for all the equipment.


JD WATER-Cup Filling And Sealing Machine | Automatic Cup Sealing Machine-6


◇◆ Our Service


JD WATER-Cup Filling And Sealing Machine | Automatic Cup Sealing Machine-7

JD WATER-Cup Filling And Sealing Machine | Automatic Cup Sealing Machine-8

Quality Assurance

JD WATER-Cup Filling And Sealing Machine | Automatic Cup Sealing Machine-9

Install

JD WATER-Cup Filling And Sealing Machine | Automatic Cup Sealing Machine-10

In-kind shooting

JD WATER-Cup Filling And Sealing Machine | Automatic Cup Sealing Machine-11

Logistics


After the machines arrives at the customer's factory, our company can arrange engineers to customer's factory to install and debug the equipment, make the machines run to the best working condition;the engineers also can train customer's staff about how to operation and maintenance of the equipment, customers also can arrange their engineers to study in our factory for free . During the warranty period,we provide the easy damage parts for free.
